WORKSAFE / SECURITY BOATS

HAND CRAFTED QUALITY WITH NEW TECHNOLOGY FOR THE ULTIMATE PATROL OPERATIONS.

WORKSAFE 1000



Work safe is new division of ARYA SHIPYARD & ARYAN BOAT. Worksafe division builds strong, reliable, secure and fast security and safety boats. WorkSafe boats build from different material according to conditions. Current WORKSAFE ranges are building from Steel, Aluminum and Polymer (HDPE). Worksafe is offering various design and equipments . Modern and Strong hull design allows our vessels to operate in tough conditions.

- Do You Need Boat For Yesterday?

- We have PATROL BOATS ready to deliver all time.

Ask For Current AVAILABILITIES.

- Our maximum delivery time for standard Patrol Boats are 3 months for Steel and Aluminum, 2 months for Polymer (HDPE) boats.

-Don’t worry about type of equipments; We offer different maker list. Even we can use your purchased equipments

POLYMER PATROL BOATS / HDPE
WORKSAFE RIB / 6,8,10,12,15m -POLYMER *RIGID UNSINKABLE



Characteristics


Hull
: POLYMER *RIGID UNSINKABLE
Superstructure
: POLYMER
Length o.a.
: 11.70 meter
Beam o.a.
: 3.70 m
Weight *single engine
: 2500kg
Weight * twin engines : 3400kg
Draft Min : 0.60 m * With Waterjet sytem
Draft Max
: 1.05 m * With Shaft drive system
Total tank capacity
: 2 m³ -
Power range (total)
: between270hp to 740 hp
Speed range : 20 - 42 knots
WORKSAFE 1000 / 10m -POLYMER *RIGID UNSINKABLE



Characteristics


Hull
: POLYMER *RIGID UNSINKABLE
Superstructure
: POLYMER
Length o.a.
: 9.90 meter - 32.4 feet
Beam o.a.
: 3.40 m - 11.1 feet
Weight *single engine
: 4550kg
Weight * twin engines : 5100kg
Draft Min : 0.70 m * With Waterjet sytem
Draft Max
: 1.15 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 370hp to 1540 hp
Speed range : 20 - 42 knots
WORKSAFE 1200 /12m -POLYMER *RIGID UNSINKABLE



Characteristics


Hull
: POLYMER *RIGID UNSINKABLE
Superstructure
: POLYMER
Length o.a.
: 11.70 meter
Beam o.a.
: 3.70 m
Weight *single engine
: 7500kg
Weight * twin engines : 8200kg
Draft Min : 0.70 m * With Waterjet sytem
Draft Max
: 1.15 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 370hp to 1540 hp
Speed range : 20 - 42 knots
WORKSAFE 1300 FW / 13m -POLYMER *RIGID UNSINKABLE



Characteristics


Hull
: POLYMER *RIGID UNSINKABLE
Superstructure
: POLYMER
Length o.a.
: 12.70 meter -41.6 feet
Beam o.a.
: 3.70 m - 12 feet
Weight *single engine
: 8150kg - 17.956 pound
Weight * twin engines : 9150kg - 20.170 pound
Draft Min : 0.70 m * With Waterjet sytem
Draft Max
: 1.15 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 370hp to 1540 hp
Speed range : 20 - 42 knots
WORKSAFE 1500 - CP / 15m -POLYMER *RIGID UNSINKABLE



Characteristics


Hull
: POLYMER *RIGID UNSINKABLE
Superstructure
: POLYMER
Length o.a.
: 14.95 meter
Beam o.a.
: 4.40 meter
Weight * twin engines : 16000 kg
Draft Min : 0.70 m * With Waterjet sytem
Draft Max
: 1.20 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 640hp to 1540 hp
Speed range : 20 - 42 knots
WORKSAFE 1700 / 17m -POLYMER *RIGID UNSINKABLE



Characteristics


Hull
: POLYMER *RIGID UNSINKABLE
Superstructure
: POLYMER
Length o.a.
: 17.50 meter
Beam o.a.
: 5.50 m
Weight * twin engines : 18000kg
Draft Min : 0.80 m * With Waterjet sytem
Draft Max
: 1.20 m * With Shaft drive system
Total tank capacity
: 4 m³
Power range (total)
: between 1200hp to 1800 hp
Speed range : 20 - 35 knots
ALUMINUM PATROL BOATS
WORKSAFE 1000AL/ST / 10m -Rigid Aluminum hull with polymer fender system.



Characteristics


Hull
: STEEL OR ALUMINUM
Superstructure
: STEEL OR ALUMINUM
Length o.a.
: 11.70 meter -40 feet
Beam o.a.
: 4.40 m
Weight * twin engines : 17000kg
Draft Min : 0.80 m * With Waterjet sytem
Draft Max
: 1.20 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 1000hp to 1540 hp
Speed range : 20 - 34 knots
WORKSAFE 1500ST-02/ 15m -Rigid Aluminum hull with polymer fender system.



Characteristics


Hull
: STEEL OR ALUMINUM
Superstructure
: STEEL OR ALUMINUM
Length o.a.
: 14.95 meter -49 feet
Beam o.a.
: 5.00 m
Weight * twin engines : 20.000kg
Draft Min : 0.80 m * With Waterjet sytem
Draft Max
: 1.20 m * With Shaft drive system
Total tank capacity
: 4 m³
Power range (total)
: between 1200hp to 1540 hp
Speed range : 20 - 28 knots
WORKSAFE 1500AL / 15m -Rigid Aluminum hull with polymer fender system.



Characteristics


Hull
: STEEL OR ALUMINUM
Superstructure
: STEEL OR ALUMINUM
Length o.a.
: 14.95 meter -49 feet
Beam o.a.
: 4.40 m
Weight * twin engines : 17000kg
Draft Min : 0.80 m * With Waterjet sytem
Draft Max
: 1.20 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 1000hp to 1540 hp
Speed range : 20 - 34 knots
WORKSAFE 1700STAL-02 / 17m -Steel hull & Aluminum Superstructure.



Characteristics


Hull
: STEEL OR ALUMINUM
Superstructure
: STEEL OR ALUMINUM
Length o.a.
: 14.95 meter -49 feet
Beam o.a.
: 4.40 m
Weight * twin engines : 17000kg
Draft Min : 0.80 m * With Waterjet sytem
Draft Max
: 1.20 m * With Shaft drive system
Total tank capacity
: 3 m³ - 790 gallon
Power range (total)
: between 1000hp to 1540 hp
Speed range : 20 - 34 knots
WORKSAFE 2000STAL-01 / 20m -Rigid Aluminum hull with polymer fender system.

20m PILOT BOAT



Characteristics


Hull
: STEEL OR ALUMINUM
Superstructure
: STEEL OR ALUMINUM
Length o.a.
: 20.00 meter
Beam o.a.
: 5.70 m
Weight * twin engines : 32.000kg
Draft : 1.40 m
Total tank capacity
: 10 m³
Power range (total)
: between 1600hp to 2400 hp
Speed range : 20 - 28 knots
WATERJET DRIVE SYSTEM

SHAFT DRIVE SYSTEM

STERN DRIVE SYSTEM OUTBOARD ENGINE DRIVE SYSTEM
